Distributor in India for HUBA CONTROL, SWITZERLAND
CS Instrument & Controls, started in 2009 in India, is a distributor to HUBA CONTROL, Switzwerland, for all of their pressure, level and flow measuring technologies.
We market a wide range of products like relative, absolute and differential Pressure Transmitters, Mechanical Pressure Switches, Electronic Pressure Switches Pressure Level Transmitters, Flow Sensors etc.
Relative & Differential Pressure Transmitter type 699
Differential pressure transmitter 699
-1 ... 1 mbar / 0 ... 0.3 - 50 mbar
These pressure transmitters type 699 are available in switchable pressure ranges and with digital device or Modbus. The full-version includes customer specific adjustment possibilities. Especially developed sensors for each pressure range allow a physically correct and long term stable measurement. The large variety offers a manifold use in the air-conditioning technique as well as for fine measurement in industry or medical applications.
click here for full specification
Relative & Absolute Pressure Transmitter type 528
Pressure transmitter 528
–1 ... 0 – 60 bar
The compact type 528 pressure transmitter is based upon the well proven ceramic technology developed by Huba Control over 20 years ago. These pressure transmitters are suitable for applications across a broad spectrum of industries.
click here for full specification
OEM Flow sensor type 200 for liquid
OEM Flow sensor 200
0.5 ... 150 l/min
The flow sensor type 200 is based on the Kármán vortex street. You can choose between various versions as integrated temperature measurement. This flow sensor without moving parts is insensitive to pollution and persuade by very few loss of pressure and a very high accuracy.
click here for full specification
OEM Mechanical relative & differential Pressure Switch type 604
Mechanical Pressure Switch 604
0.2 ... 50 mbar
The ideal pressure switch to control air flows in air conditioning and ventilation systems, but equally effective in industrial air monitoring applications. This product range, which is classified in 5 pressure ranges, makes installation easy with features such as combibracket, screw terminals and snap-on cover. Of unique benefit is the high adjustment accuracy resulting from individual scale engraving..
click here for full specification
Electronic relative Pressure Switch programmable type 540
Electronic Pressure Switch 540
0 ... 60 – 600 bar
The µP-regulated, programmable pressure transmitter type 540 has a robust industry design. The parameters are easily adjustable with two function keys in the configuration menue which disposes of up to two programmable switching points. All systems are equipped with a diag nostic function. The large 4 digit LED display assures a good accuracy of reading. The pressure switch type 540 is based upon the Huba Control developed thick film technology where the pressure measuring cell is fully welded..
click here for full specification
Pressure level transmitter type 681
Pressure level transmitter 681
0 ... 0.1 - 25 bar
The level sensing transmitter of type 681 with piezoresistive measuring elements have compensated, adjusted and amplified sensor signals which are available as standard voltage or current outputs. In the immersion-sensor version with a salt water and oil-resistant connection cable they are specially suited for level measurement, even in the presence of corrosive liquids. The cable incorporates a tube for compensation of the ambient pressure. Manufactured from stainless steel, its welded construction provides a watertight seal..
click here for full specification
